RuiDa's Urea Formaldehyde Moulding Powder (injection grade) are based on urea formaldehyde resin and takes cellulose, minerals as the filling, together with both lubricant, hardener and pigment, etc.
UF1I-1109: granule form, injection grade; color: white
Product Properties
1. Products own bright and smooth surface, and have no bubble as well as crevice. The tinge and impurity confirm to the standard sample..
2. No black spot, stable injection properties, special for electrical appliance
3. Color difference: Delta E <1.0
Applications
Electrical appliance, such as lamp holder, socket, plug, dash board, insulated parts etc.
Kitchenware handle, knobs.
Color Difference
Color standard | L | a | b |
87.25 | 0.45 | -0.22 | |
Acceptance range | 0~0.6 | ±0.2 | ±0.3 |
△E：≤0.8 | |||
Production Specification
Number | Test Items | Index | Test Result |
1 | Fluidity, mm | 110-140 | 125 |
2 | Volatile Content % ≤ | 5.00 | 3.45 |
3 | Exterior | Qualified | |
4 | Boiling Water-proof | Qualified | |
5 | Flexural Strength, Mpa ≥ | 80 | 85 |
6 | Impact Strength, KJ/㎡ ≥ | 1.7 | 1.8 |
7 | Temperature of hot distortion, ℃ ≥ | 115 | 125 |
8 | Water absorption(Cold water) mg ≤ | 100 | 65 |
9 | Molding Shrinkage, % | 0.5-1.0 | 0.82 |
10 | Dielectric resistance after 24h in water, MΩ ≥ | 104 | 2.6*105 |
11 | Dielectric Strength, MV/m ≥ | 7.0 | 10 |
Certificate
Our Advantage
1. More than 36 years experience in this field.
2. Special in producing granular injection grade urea molding compound.
3. Big production capacity, 20 tons/day, small order is acceptable.
